EARTHING & SHORT CIRCUITING KITS

From: USD 1,156.00

From: USD 1,156.00

Short Circuiting and Grounding Equipment with Contact Clamps for Electric Cabins and MV Installations with cables sections.

● n°3 Screw type contact clamps type PF20 – PF25 made by press forged brass with hexagonal tang for connection to the insulating rod (bayonet DIN tang on demand).
Clamping capacity:
* ball earth fixed points 20 – 25 mm diameter. (Please indicate the ball earth fixed points required in the event of an order);
* round conductors and flat bars up to 22 mm.
● n°3 Extraflexible electrolytic copper cables of short circuit, covered by transparent PVC sheath, for the connection between the three contact clamps and the central connector, length 0,75 m, complete, at the extremities, of tinning copper lugs and reinforcements by transparent heat-shrink sheath.
● Central trifurcating connector.
● Ground electrolytic copper cable, characteristics as above, length 2 m.
● Ground clamp made by press forged brass, clamping capacity up to 22 mm.
● Insulating fiberglass rod type PE2/135EF (or other length) made of epoxy resin reinforced by fiberglass certified in conformity with the International Standard CEI EN 61235, Length 1,35 m in two elements connected between them by quick coupler.
● Metallic carrying case.

Copy Variation Url
Model No.: MT/PF
Origin: Italy

Short Circuiting and Grounding Equipment with Contact Clamps for Electric Cabins and MV Installations with cables sections.

● n°3 Screw type contact clamps type PF20 – PF25 made by press forged brass with hexagonal tang for connection to the insulating rod (bayonet DIN tang on demand).
Clamping capacity:
* ball earth fixed points 20 – 25 mm diameter. (Please indicate the ball earth fixed points required in the event of an order);
* round conductors and flat bars up to 22 mm.
● n°3 Extraflexible electrolytic copper cables of short circuit, covered by transparent PVC sheath, for the connection between the three contact clamps and the central connector, length 0,75 m, complete, at the extremities, of tinning copper lugs and reinforcements by transparent heat-shrink sheath.
● Central trifurcating connector.
● Ground electrolytic copper cable, characteristics as above, length 2 m.
● Ground clamp made by press forged brass, clamping capacity up to 22 mm.
● Insulating fiberglass rod type PE2/135EF (or other length) made of epoxy resin reinforced by fiberglass certified in conformity with the International Standard CEI EN 61235, Length 1,35 m in two elements connected between them by quick coupler.
● Metallic carrying case.
